Feature
- Rotation and revolution independent variable mechanism mounted
- Twin system, Maximum Capacity 250ml/400g × 2 (gross)
- Mixing capacity can mix high-viscosity material such as viscous grease with viscosity 4,000Pa s
- Can use a sensor unit that can detect temperature of materials being mixed in real time (optional)
- Effective in setting recipes for materials that do not like temperature rise
- Through external PC connections, can display recipe settings, rotations during operation, and material temperature in real time (USB Type B standard equipment)
- Can remote control through external PC connections (optional RS485 terminal)
Specification
| Model | ARE-400TWIN |
|---|---|
| Maximum Capacity | 400 g×2 *1：Total mass to mount on the cup holder, including materials, containers, and adapters. |
| Standard Container*2 | 300 ml resin container *2：Contact us because the actual volume of mixing may vary depending on the containers, materials, and conditions. |
| Power Supply | Voltage : Single-phase AC 100 V ± 10 %, 50/60 Hz Power consumption : Approx. 50 VA (standby) Max. 1400 VA (operation) |
| Unit Dimensions | H560 × W460 × D480（mm） |
| Unit weight | Approx. 70 ㎏ |
| Accessories | Instruction Manual x 1, AC cable (including 3P adapter) x 1, HDPE 300 ml container x 6 pcs, PC Management Software (Allows you to easily set / manage number of revolutions / number of rotations / operating time.) + (Allows you to check the number of revolutions / processing / temperature on a PC in real time.), USB cable (TypeB) x 1, L-shaped wrench (for M6) x 1, Key to unlock door during power failure x 1 |
| Option | Real-time temperature monitoringfunction (used with dedicatedsensor unit) |
