Feature
- Simultaneous mixing, dispersion, and removal of foam at submicron level. Can handle low- to high-viscosity materials.
- The rotation and revolution method and the vacuum decompression function enable high-precision defoaming in a short time without spilling during operation.
- Real-time display of progress and operation status on touch panel.
- Twenty recipes can be registered by touch operation.
- The communication function (RS-232C connection) contributes to traceability improvement by operation and data acquisition using an external terminal.
- CE certified model is available
Specification
| Model | ARV-310P |
|---|---|
| Maximum Capacity | 310 g *1：Total mass to mount on the cup holder, including materials, containers, and adapters. |
| Standard Container*2 | 300 ml resin container *2：Contact us because the actual volume of mixing may vary depending on the containers, materials, and conditions. |
| Power Supply | Voltage : Single-phase AC 100 V ± 10 %, 50/60 Hz Power consumption : Approx. 50 VA (standby) Max. 1200 VA(operation) |
| Unit Dimensions | H450 × W555 × D645（mm） |
| Unit weight | Approx. 90 kg |
| Accessories | Instruction Manual x 1, AC cable (including 3P adapter) x 1, HDPE 300 ml container x 3 pcs, 150 ml container x 1 pc, Adapter for 150 ml container x 1 pc (including 1 rubber ring), Box wrench x 1, Hexagon wrench x 1, Waste oil receiver x 1, Funnel x 1 |
