YAG, Silicate etc.
White LED is used in the automotive industry, as backlight of mobile phones, and for illumination. Used for sealing LED chips, it is composed of high-density fluorescent substance and low-viscosity silicone resin.
|Material||YAG, Silicate etc.|
|Unit||THINKY MIXER ARV-310LED|
|Operation time setting||400rpm Non vacuum 30sec+ 1200rpm 0.6Kpa 3min|
|Material Viscosity||3000-5000 mPa・s|
THINKY MIXER （Vacuum） ARV-310LED
・Simultaneous mixing, dispersion, and submicron-level air bubble elimination
・Deaeration of high-viscosity materials difficult to be processed by a centrifugal separator
・Reduced processing time and improved deareation performance compared to the atmospheric type mixer
・Centrifugal force of revolution prevents overflow of material during operation
・High-specific-weight materials such as fluorescent material can be evenly dispersed and deaerated without sedimentation (ARV-310LED)
